JLG Boom Cylinder Seal Kit 7017184 – 1250AJP, 1350SJP Telescopic Extension

Save $40

Can't find what you are looking for?
Contact us, we can help you find the part you need.

Price:

$280 USD $320 USD

Chat Now

Share this product

Seal Kit 7017184 – Optimized Product Page Content

JLG Boom Cylinder Seal Kit 7017184

🔹 Product Overview

The Seal Kit with JLG Part Number 7017184 is a heavy-duty, critical seal set specifically designed for the Primary Hydraulic Cylinder (often the telescope or extension cylinder) used in the largest JLG Telescopic Boom Lifts, including the 1250AJP, 1200SJP, and 1350SJP models.

These large cylinders are subjected to immense hydraulic pressures and loads as they extend and retract the multi-section boom. When the seals within this primary cylinder wear, they cause external fluid leaks (weeping from the end gland) or, more dangerously, internal bypass (fluid leaking past the piston). Internal bypass leads directly to boom sections drifting or retracting unexpectedly, which is a severe safety hazard.

Using the 7017184 seal kit allows for a complete overhaul of the cylinder, restoring its ability to hold pressure under load, eliminating fluid leaks, and ensuring the stability and reliability of the super-boom’s extension function.

🔹 Key Features & Benefits

✅ Super-Boom Cylinder Repair: Specifically formulated kit for rebuilding the primary telescope/extension cylinder on JLG’s large boom lifts.
✅ Heavy-Duty Construction: Seals and wear rings are designed to withstand the extremely high pressures of super-boom extension systems.
✅ Eliminates Boom Drift: Restores internal piston sealing integrity, preventing the extended boom sections from creeping inward.
✅ Cost-Effective Solution: Repairs the existing, highly specialized cylinder, offering substantial savings over a full component replacement.
✅ Direct Replacement: High-quality aftermarket or genuine OEM equivalent for JLG seal kit 7017184.

🔹 Technical Details

Detail	Specification
JLG Seal Kit PN	7017184
Cross-Reference	Varies based on cylinder dimensions (Verify application details).
Condition	New Aftermarket or Original Equipment Manufacturer (OEM)
Type	Hydraulic Cylinder Seal Kit (Telescopic Boom Extension)
Components	Rod Seal, Piston Seal, Wear Rings, Wiper, O-rings, Back-up Rings
Function	Seals the cylinder rod and piston to maintain hydraulic pressure for boom extension and retraction.
Intended Use	Repair/Rebuild of Main Telescope/Extension Cylinders on Large JLG Boom Lifts.
Installation Note	Requires specialized tools and extreme care due to cylinder size and high operating pressure.
Warranty	Standard warranty against manufacturing defects (varies by supplier)

🔹 Compatible JLG Models & Applications

The Seal Kit 7017184 is vital for maintaining the primary hydraulic function of JLG’s largest telescopic booms. Always verify the specific cylinder part number on your machine against the kit’s compatibility list before purchase.

JLG Equipment Series	Specific Compatible Models (Examples)
Ultra Series Boom Lifts	1250AJP, 1200SJP, 1350SJP, 1500SJ (Verify cylinder application)
Common Application	Fixing external leaks and internal bypass in the primary telescopic cylinder that controls the horizontal reach and stability of the main boom.

🔹 Why Choose a Quality 7017184 Seal Kit?

Critical Safety Fix: Ensures the boom sections hold their position securely, vital for the safety of workers at extreme heights.
Component Longevity: Rebuilding the cylinder extends the life of this massive, highly expensive component.
Precision Sealing: Seals are manufactured from compounds rated for the peak pressures and loads experienced in ultra-series boom operations.
Reliability: Eliminates fluid loss and internal pressure drop, ensuring the machine operates to its full reach and capacity.
