Elbow Fitting 13921GT – Optimized Product Page Content
🔹 Product Overview
The Elbow Fitting with Genie Part Number 13921GT is a specific hydraulic connector used within the fluid power systems of various Genie Mobile Elevated Work Platforms (MEWPs). This component is referenced by the fitting specification 07022-4-4, indicating its size, thread type, and angle.
This elbow is a standard but critical piece of hardware used to route hydraulic lines (hoses or tubes) at a 90-degree angle, ensuring leak-free connections between key hydraulic components such as pumps, valves, cylinders, and reservoirs. It helps manage hydraulic line routing in tight spaces within the lift’s chassis or boom assembly.
Although a small part, failure or leakage in a hydraulic fitting like the 13921GT can lead to pressure loss, fluid contamination, and ultimately, failure of the lift’s hydraulic functions. It is an essential component for any major hydraulic repair or hose replacement on compatible Genie models.
🔹 Key Features & Benefits
- ✅ Hydraulic System Component: Essential fitting for connecting hydraulic hoses and tubes within the lift’s fluid power circuits.
- ✅ 90-Degree Angle: Allows for precise routing of hydraulic lines in confined areas, minimizing hose stress.
- ✅ Standardized Specification: Complies with the industry standard 07022-4-4 fitting type for guaranteed compatibility.
- ✅ Leak-Free Connection: Manufactured to tight tolerances to ensure a reliable, high-pressure seal.
- ✅ Direct Replacement: High-quality replacement for the Genie part number 13921GT.
🔹 Technical Details
| Detail | Specification |
| Genie Part Number | 13921GT |
| Fitting Specification | 07022-4-4 |
| Condition | New Aftermarket or Original Equipment Manufacturer (OEM) |
| Type | Hydraulic Elbow Fitting (90-degree) |
| Material | High-strength steel, suitable for high-pressure hydraulic fluid. |
| Function | Connects two hydraulic lines at a 90-degree angle. |
| Intended Use | Hydraulic systems on Genie Boom Lifts and Scissor Lifts. |
| Installation Note | Requires proper torqueing to prevent leaks. |
| Warranty | Standard warranty against manufacturing defects (varies by supplier) |
🔹 Compatible Genie Models & Applications
The Elbow Fitting 13921GT is a widely used hydraulic component found across the fluid power systems of numerous Genie equipment models. Always verify the specific fitting required by your hose or pump configuration before ordering.
| Genie Equipment Series | Specific Compatible Models (Examples) |
| Boom Lifts (Z/S Series) | Various models including S-60, Z-45/25, S-85 |
| Scissor Lifts (GS Series) | Various models including GS-2646, GS-3246 |
| Telehandlers (GTH Series) | Various models (where applicable) |
| Common Application | Found throughout the entire hydraulic system, including manifold blocks, valve connections, and cylinder ports. |
🔹 Why Choose a Quality 13921GT Replacement?
- Safety Assurance: Ensures the hydraulic system maintains the necessary pressure without leaks, crucial for safe lift operation.
- Corrosion Resistance: Made from durable materials to withstand exposure to hydraulic fluid and environmental factors.
- Guaranteed Fit: Manufactured precisely to the 07022-4-4 specification, ensuring a perfect thread match and seal.
- Essential Maintenance: Necessary replacement during hydraulic component overhauls or when repairing leaking hose connections.
