Harness 110245GT – LS2 OP Primary Boom Control Loom

RQ Parts - Genie Harness 110245GT Electrical Loom for Primary Boom Control System (Limit Switch 2)

🔹 Product Overview: Secondary Primary Boom Position Sensing Circuitry

The Wiring Harness Assembly with part number 110245GT (and its predecessor 110245) is a highly specialized electrical component designed for the intricate and safety-redundant boom control systems of various Genie Articulating Boom Lifts (commonly Z-Series).

The designation “HARNESS LS2 OP PRIMARY” indicates its specific, safety-critical role: this loom connects the Limit Switch 2 (LS2) and Operational (OP) sensors/switches that monitor the position and operational status of the Primary Boom section. In many Genie boom lifts, multiple limit switches (LS1, LS2, etc.) are used redundantly or at different points of travel to ensure accurate sequencing, stability, and control, especially for the main lifting cylinder or primary telescope section. This harness ensures clean, reliable signal transmission between these key sensors and the main control module.

As a high-quality aftermarket replacement supplied by RQ Parts, this 110245GT Harness offers an exact-fit solution to replace a damaged, cracked, or corroded original loom. Electrical failures in this circuit, particularly involving a primary safety sensor like LS2, can lead to system faults, reduced operational limits, or machine lockout. Replacing it ensures accurate position signaling and restored safety compliance on your Genie fleet.

🔹 Key Features & Benefits

✅ Primary Boom Focus: Dedicated harness for sensors and switches controlling the main (Primary) Boom section.

✅ Secondary Position Sensor: Integrates the signal for Limit Switch 2 (LS2), vital for safety sequencing or dual-sensor redundancy.

✅ Operational Reliability: Crucial for managing the safe and controlled movement of the primary lift structure.

✅ Direct OEM Cross-Reference: Exact match for Genie part numbers 110245GT and 110245.

🔹 Technical Details

Part Number: 110245GT (Also known as 110245) Condition: 100% new replacement Type: Wiring Harness Assembly / Electrical Loom Function: Connects switches and sensors related to Limit Switch 2 (LS2) and Primary Boom functions. Compatibility: Genie Articulating Boom Lifts (Commonly found on Z-Series models like Z-34/22 and others. Verification via machine manual is required.) Warranty: 12 months against manufacturing defects

🔹 Compatible Genie Models & Applications

The Harness 110245GT is critical to the boom control systems of various Genie Articulating Boom Lifts, including:

Genie Z-Series Lifts: Often used on Z-34/22 models (various serial number ranges and types, including IC, DC, and Bi-Energy variants).
Common Application: Typically located at the pivot point or along the primary boom section, managing connections for the position sensors (LS2) that dictate boom angle and limits.

Note: Always verify the full 110245GT part number against your machine’s model and serial number in the Genie service manual to ensure correct component replacement.

🔹 Why Choose RQ Parts?

Safety Circuit Expertise: We specialize in the complex, safety-critical harnesses that manage boom position interlocks and sequencing. Guaranteed Compatibility: Parts are verified to match the electrical and physical specifications of the OEM assembly. Competitive Pricing: High-quality replacement harnesses offered at cost-effective prices. Fast Global Delivery: Reliable logistics ensure minimal downtime, keeping your equipment operational and compliant.
