Harness 102175GT – Boom Retract Control Loom (Z-60)

RQ Parts - Genie Harness 102175GT Electrical Loom for Boom Retract Control System

🔹 Product Overview: Critical Boom Retraction Sequencing Circuitry

The Wiring Harness Assembly with part number 102175GT (and its predecessor 102175) is a specialized electrical component designed for the complex hydraulic and electronic systems of the Genie Z-60/34 Articulating Boom Lift and related Z-60 models.

The designation “HARNESS, BOOM RETRACT” clearly defines its crucial operational function: this loom connects the sensors, switches, and potentially the hydraulic valve solenoids that monitor and control the hydraulic action for Boom Retraction. Accurate and sequenced retraction is vital for the safety, stability, and proper nesting of the boom sections during operation and when moving the machine. This harness ensures clean and reliable signal transmission to the main control module to manage the retraction speed and limits.

As a high-quality replacement supplied by RQ Parts, this 102175GT Harness offers an exact-fit solution to replace a damaged, cracked, or corroded original loom. Electrical faults in this circuit can lead to inconsistent retraction speeds, system errors, or complete hydraulic failure of the boom function. Replacing it ensures reliable command transmission and restored boom operational integrity on your Genie Z-60 fleet.

🔹 Key Features & Benefits

✅ Retraction Control Focus: Dedicated harness for sensors and valves controlling the main Boom Retract function.

✅ Z-60 Specific Fit: Essential harness for the hydraulic and electronic control systems of the Genie Z-60 Articulating Boom Lift.

✅ Operational Reliability: Crucial for managing the sequenced and safe retraction of the multi-section boom.

✅ Direct OEM Cross-Reference: Exact match for Genie part numbers 102175GT and 102175.

🔹 Technical Details

Part Number: 102175GT (Also known as 102175) Condition: 100% new replacement Type: Wiring Harness Assembly / Electrical Loom Function: Connects switches, sensors, and solenoids related to Boom Retraction functions. Compatibility: Genie Z-60 Articulating Boom Lifts (Commonly Z-60/34, Z-60/37, etc. Verification via machine manual is required.) Warranty: 12 months against manufacturing defects

🔹 Compatible Genie Models & Applications

The Harness 102175GT is critical to the hydraulic control systems of the following Genie Articulating Boom Lifts:

Genie Z-Series Lifts: Z-60/34 (and various related Z-60 models)
Common Application: Typically located along the boom structure, managing connections between the control unit, boom position sensors, and the hydraulic valves that execute the retraction movement.

Note: Always verify the full 102175GT part number against your machine’s model and serial number in the Genie service manual to ensure correct component replacement.

🔹 Why Choose RQ Parts?

Specialized Hydraulic Interface: We specialize in the critical harnesses that bridge electronic controls and complex hydraulic actions, ensuring precise operation. Guaranteed Compatibility: Parts are verified to match the electrical and physical specifications of the OEM assembly. Competitive Pricing: High-quality replacement harnesses offered at cost-effective prices. Fast Global Delivery: Reliable logistics ensure minimal downtime, keeping your equipment operational and profitable.
