JLG 460SJ HC3 Telescopic Boom Lift – 52ft Diesel High Capacity with Jib 4WD
Specifications
Description
JLG 460SJ HC3 Telescopic Boom Lift – Optimized Product Page Content
🔹 Product Overview
The JLG 460SJ HC3 is a high-capacity, heavy-duty Diesel Telescopic (Straight) Boom Lift designed for maximum productivity and lifting power on rough terrain job sites.1 The “460SJ” denotes the 46-foot class with a jib, while the “HC3” (High Capacity, 3-rated) confirms the machine is engineered with JLG’s High Capacity system, offering a tri-rated platform capacity up to 1,000 lbs (454 kg). This lift combines the speed of a straight boom with the precision of a jib, and the power to handle more workers and heavy materials, making it ideal for structural steel, heavy installation, and building envelope work.
🔹 Key Specifications & Capabilities
| Detail | US Imperial | Metric |
| Max Working Height | 52 ft | 16.05 m |
| Max Platform Height | 46 ft | 14.05 m |
| Max Horizontal Outreach | 36 ft 10 in | 11.23 m |
| Platform Capacity (Tri-Rated) | 1,000 / 750 / 600 lb | 454 / 340 / 272 kg |
| Platform Jib | 4 ft | 1.22 m |
| Drive System | Diesel/Hydraulic (4WD) | Diesel/Hydraulic (4WD) |
| Gradeability (4WD) | 45 % | 45 % |
| Machine Model | 460SJ HC3 |
🔹 Key Features & Benefits
-
✅ High Capacity (HC3) System: Provides industry-leading tri-rated platform capacity up to 1,000 lb (454 kg), allowing for maximum personnel and heavy materials placement at height.
-
✅ Platform Jib: Includes a 4 ft (1.22 m) jib that provides 130° of vertical articulation, allowing for precise final positioning and the ability to work around small obstacles.
-
✅ Telescopic Boom: Provides maximum horizontal outreach and fast time-to-height, maximizing job site efficiency and covering large areas quickly.
-
✅ Rough Terrain Performance: Equipped with standard 4WD and a full-time oscillating axle, ensuring superior traction and stability for navigating slopes, mud, and uneven job sites.
-
✅ Efficient Control: Features the JLG Control System for smooth, responsive operation, even when handling heavy loads at maximum extension.
-
✅ Continuous Rotation: 360° continuous turntable rotation maximizes the work envelope.
🔹 Applications
-
Structural Steel Erection and Heavy Component Installation
-
Building Envelope Installation (Siding, Cladding, Glazing) requiring heavy materials
-
Industrial Plant Maintenance and Repair
-
Utility and Electrical Work on Unprepared Sites
-
Any outdoor task requiring long horizontal outreach, precision, and maximum capacity.
