Haulotte HS6395 E Electric Rough Terrain Scissor Lift – 69ft Height & 1654lb Capacity
Specifications
Description
Haulotte HS6395 E Electric Rough Terrain Scissor Lift – Optimized Product Page Content
🔹 Product Overview
The Haulotte HS6395 E is a next-generation model in the high-performance PULSEO range of fully electric, rough terrain Scissor Lifts. Developed for high-rise construction and industrial work, it offers the highest available reach in the PULSEO line, with a remarkable working height of 69 ft. It maintains a large platform capacity of 1,654 lb and is designed for versatility with 100% electric drive for zero-emission, silent operation. This model features a huge platform that extends up to 24 ft 7 in and comes with standard hydraulic outriggers for maximum stability on rugged and uneven ground.
🔹 Key Specifications & Capabilities
| Detail | US Imperial | Metric (Approx.) |
| Working Height | 69 ft 0 in | 21.03 m |
| Platform Height | 63 ft 0 in | 19.20 m |
| Max. Lift Capacity | 1,654 lb (4 pers.) | 750 kg |
| Platform Length (Extended) | 24 ft 7 in | 7.49 m |
| Overall Length (Stowed) | 16 ft 3 in | 4.95 m |
| Overall Width | 7 ft 11 in | 2.41 m |
| Height – Stowed (Guardrails Down) | 8 ft 11 in | 2.72 m |
| Weight | 23,369 lb | 10,600 kg |
| Drive System | Full Electric (AC Motors), 4WD | Electric, 4WD |
| Gradeability | 38 % | 38 % |
| Ground Clearance | 11 in | 28 cm |
| Machine Model | HS6395 E (PULSEO) |
🔹 Key Features & Benefits
-
✅ Maximum Electric Reach: Achieves the highest working height in the Haulotte electric rough terrain range at 69 ft, suitable for extreme high-rise projects.
-
✅ Full-Height Drive Capability: The machine is capable of being driven at its full height with no load restrictions (on appropriate surfaces), boosting on-site efficiency.
-
✅ Superior Platform Size: Features a massive 24 ft 7 in maximum platform length with dual extensions, offering the largest available workspace in its class for materials and crew.
-
✅ Zero-Emission Operation: 100% electric drive with 72V Lithium-ion batteries (backed by a 5-year warranty) ensures quiet, clean operation for indoor and outdoor use.
-
✅ Rough Terrain Performance: Includes 4-wheel drive (4WD) and a manual/automatic differential lock for optimum grip and a strong 38% gradeability.
-
✅ Stability and Safety: Standard hydraulic outriggers with automatic or individual setup ensure secure leveling and stability on difficult or sloping terrain.
-
✅ Extended Autonomy: Offers an optional removable Range Extender (5.2 kW) for hybrid capability and continuous work over extended periods with minimal fuel consumption.
🔹 Applications
-
High-rise structural work, glazing, cladding, and industrial maintenance on large, demanding outdoor construction sites.
-
Projects requiring a combination of extreme vertical reach, vast platform area, and substantial lifting capacity.
-
Environments where noise and air pollution must be minimized without sacrificing power or reach.
