Haulotte HS4390 E Electric Rough Terrain Scissor Lift – 48ft Height & 1654lb Capacity
Specifications
Description
Haulotte HS4390 E Electric Rough Terrain Scissor Lift – Optimized Product Page Content
🔹 Product Overview
The Haulotte HS4390 E is a model from the revolutionary PULSEO range of fully electric, rough terrain Scissor Lifts. It offers the drive performance of a diesel machine while being completely silent and emission-free. Designed for challenging construction sites, it provides a high working height of 48 ft 8 in and an industry-leading capacity of 1,654 lb. Key features include 4-wheel drive (4WD), a manual locking differential for superior traction, standard hydraulic outriggers, and advanced energy management, allowing it to be used throughout the entire construction project, indoors and out.
🔹 Key Specifications & Capabilities
| Detail | US Imperial | Metric (Approx.) |
| Working Height | 48 ft 8 in | 14.83 m |
| Platform Height | 42 ft 8 in | 13.00 m |
| Max. Lift Capacity | 1,654 lb (4 pers.) | 750 kg |
| Platform Length (Extended) | 16 ft 1 in | 4.90 m |
| Overall Length (Stowed) | 14 ft 5 in | 4.39 m |
| Overall Width | 7 ft 7 in | 2.31 m |
| Height – Stowed (Guardrails Down) | 7 ft 5 in | 2.26 m |
| Weight | 16,577 lb | 7,520 kg |
| Drive System | Full Electric (AC Motors), 4WD | Electric, 4WD |
| Gradeability | 45 % | 45 % |
| Ground Clearance | 13 in | 33 cm |
| Machine Model | HS4390 E (PULSEO) |
🔹 Key Features & Benefits
-
✅ Full Electric, Rough Terrain: Offers the superior performance of a rough terrain lift with zero emissions and silent operation, suitable for indoor/outdoor use on uneven ground.
-
✅ Extreme Capacity & Reach: Features a high working height of nearly 49 ft and an unmatched platform capacity of 1,654 lb (4 people).
-
✅ Off-Road Drive Performance: Equipped with 4WD and a mechanical axle with a manual locking rear differential to ensure excellent traction and a high 45% gradeability.
-
✅ Hydraulic Outriggers: Standard outriggers with centralized or individual controls allow for quick leveling and safe operation on highly sloped or rugged terrain.
-
✅ Extended Duty Cycles: Features Haulotte Activ’Energy Management for optimal battery health and offers an optional low-fuel-consumption Range Extender for non-stop work.
-
✅ Maximized Work Space: The platform extends up to 16 ft 1 in long, with optional dual extensions available to reach 24 ft 7 in for massive work areas.
🔹 Applications
-
High-reach structural construction, steel erection, and facade installation on rough or outdoor sites.
-
Projects requiring a large platform and high capacity for multiple workers and heavy tools.
-
Sensitive outdoor environments, restricted zones, and facilities where noise and emissions must be minimized.
