Haulotte HA32 CJ Electric Articulating Boom Lift – 37ft Height, 3’11” Width
Specifications
Description
Haulotte HA32 CJ Articulating Boom Lift – Optimized Product Page Content
🔹 Product Overview
The Haulotte HA32 CJ is a compact, electric Articulating Boom Lift designed for maximum maneuverability in tight, restricted spaces, both indoors and outdoors on even ground. Despite its compact footprint, it offers an excellent working height of 37 ft 9 in and a significant horizontal outreach of 23 ft 2 in. Its key features include a zero tailswing design and a narrow 3 ft 11 in width, allowing it to easily pass through standard doorways and operate in congested areas like warehouses, retail centers, and industrial facilities.
🔹 Key Specifications & Capabilities
| Detail | US Imperial | Metric (Approx.) |
| Working Height | 37 ft 9 in | 11.51 m |
| Platform Height | 31 ft 9 in | 9.68 m |
| Horizontal Outreach | 23 ft 2 in | 7.06 m |
| Up and Over Clearance | 15 ft 7 in | 4.75 m |
| Max. Lift Capacity | 550 lb (2 pers.) | 250 kg |
| Overall Width | 3 ft 11 in | 1.19 m |
| Length (Transport) | 12 ft 8 in | 3.86 m |
| Height – Stowed | 6 ft 6 in | 1.98 m |
| Weight | 15,578 lb | 7,066 kg |
| Drive System | 48 V DC Electric (2 Wheel Drive) | Electric (2WD) |
| Gradeability | 25 % | 25 % |
| Turning Radius – Outside | 12 ft 0 in | 3.66 m |
| Machine Model | HA32 CJ |
🔹 Key Features & Benefits
-
✅ Ultra-Compact Design: With an overall width of just 3 ft 11 in and zero tailswing, it provides outstanding maneuverability, making it ideal for narrow aisles and crowded work areas.
-
✅ Excellent Outreach: Offers a significant 23 ft 2 in of horizontal reach, giving operators exceptional access for work over obstacles.
-
✅ Optimal Productivity: Features simultaneous drive and rotation, long working cycles, and a max drive speed of 3.7 mph for efficient positioning and site movement.
-
✅ Environmentally Friendly: 48 V DC electric drive system with solid non-marking tires is suitable for clean, silent indoor applications and even outdoor surfaces.
-
✅ Standard Equipment: Includes a self-closing swing gate, automatic platform leveling, AC power to the platform, and fully proportional controls.
🔹 Applications
-
Interior fit-out, maintenance, and facility management in shopping centers, airports, and public buildings.
-
Installation and finishing work in tight industrial and logistic/retail environments.
-
Maintenance and renovation work requiring high maneuverability and outreach on level flooring.
