Haulotte 3632 T Telescopic Trailer Mounted Boom Lift – 43ft Height & 32ft Outreach
Specifications
Description
Haulotte 3632 T Telescopic Trailer Mounted Boom Lift – Optimized Product Page Content
🔹 Product Overview
The Haulotte 3632 T is a specialized Telescopic Trailer Mounted Boom Lift (also known as a Towable Boom Lift or ‘Articulated & Telescopic Trailer’ by Haulotte). Designed for extreme horizontal reach, it provides 32 ft of outreach with a working height of 43 ft 6 in. Highly popular with tradesmen and local communities, its compact, lightweight design allows it to be towed by a standard half-ton pickup truck without requiring a Commercial Driver’s License (CDL). Hydraulic outriggers provide automatic leveling and fast, safe setup on uneven ground. The “T” in the model name often denotes a purely telescopic boom, which maximizes outreach at certain heights compared to articulated models.
🔹 Key Specifications & Capabilities
| Detail | US Imperial | Metric (Approx.) |
| Working Height | 43 ft 6 in | 13.26 m |
| Platform Height | 36 ft 0 in | 10.97 m |
| Horizontal Outreach | 32 ft 0 in | 9.75 m |
| Up and Over Height | N/A | N/A |
| Lift Capacity | 500 lb | 227 kg |
| Jib Length | N/A | N/A |
| Length – Stowed | 22 ft 8 in | 6.91 m |
| Width – Stowed | 5 ft 6 in | 1.68 m |
| Height – Stowed | 6 ft 8 in | 2.03 m |
| Weight (No Options) | 4,400 lb | 1,996 kg |
| Power Source | Electric (4 x 6V Batteries) | Electric |
| Tow Speed Rating | 65 mph | 105 km/h |
| Leveling Capability | Up to 8° Slope | Up to 8° Slope |
| Machine Model | 3632 T |
🔹 Key Features & Benefits
-
✅ Extreme Outreach: Provides a massive 32 ft of horizontal outreach, allowing operators to reach significantly farther than the boom’s platform height might suggest.
-
✅ Maximum Portability: Lightweight construction and 65 mph tow rating allow towing by a standard half-ton pickup; No CDL required.
-
✅ Rapid & Safe Setup: Hydraulic outriggers enable automatic leveling and safe elevation on slopes up to 8 degrees in under 30 seconds.
-
✅ On-Platform Utilities: Includes 110V GFI protected power outlet, air line, and water line to the platform, boosting on-site productivity.
-
✅ Turntable Rotation: Offers 700° non-continuous turntable rotation for exceptional positioning flexibility around the work area.
-
✅ Extended Operation: 100% battery-powered for quiet, clean operation, with an optional DC/Gas generator for extending duty cycles.
🔹 Applications
-
Exterior building maintenance and painting where maximum side reach is needed.
-
Utility and telecommunications work requiring long, horizontal extensions over obstacles.
-
Landscaping and event setup on moderate slopes where precise leveling is crucial.
