Genie Z-34/22 DC Articulated Boom Lift – 40ft Electric Z-Boom
Specifications
Description
Genie Z-34/22 DC Articulated Boom Lift – Optimized Product Page Content
🔹 Product Overview
The Genie Z-34/22 DC is a classic DC electric-powered articulated (Z-Boom) lift known for its versatility, quiet operation, and excellent reach in indoor and slab environments.1 The “DC” designation confirms its clean, battery-electric power source, making it the preferred choice for facilities and construction sites requiring zero emissions.2 It offers impressive up-and-over clearance and articulation capabilities, allowing operators to easily maneuver around obstacles, making it ideal for maintenance, installation, and inspection tasks in congested industrial and commercial settings.
🔹 Key Specifications & Capabilities
| Detail | US Imperial | Metric |
| Max Working Height | 40 ft 8 in | 12.52 m |
| Max Horizontal Reach | 22 ft 3 in | 6.78 m |
| Up and Over Clearance | 14 ft 4 in | 4.37 m |
| Platform Capacity | 500 lb | 227 kg |
| Machine Width | 5 ft 8 in | 1.73 m |
| Turntable Rotation | 355° Non-Continuous | 355° Non-Continuous |
| Power Source | 48V DC (Electric) | 48V DC (Electric) |
| Machine Model | Z-34/22 DC |
🔹 Key Features & Benefits
-
✅ Zero-Emission Electric Power: The 48V DC electric system ensures quiet, fume-free, and clean operation, essential for indoor use in factories, public spaces, and environmentally sensitive areas.
-
✅ Up-and-Over Capability: The articulating boom design provides excellent up-and-over clearance, allowing operators to effortlessly reach over machinery, fixed obstacles, and equipment.
-
✅ Maneuverability: Features a narrow turning radius and precise proportional controls, enhancing efficiency and positioning accuracy in tight industrial and commercial quarters.
-
✅ Versatile Access: Ideal balance of vertical and horizontal reach for a wide variety of maintenance and construction applications.
-
✅ Long Battery Life: Designed for a full day’s work on a single charge, minimizing interruptions and maximizing productivity.
-
✅ Non-Marking Tires: Equipped with standard non-marking tires to protect sensitive indoor flooring and slab surfaces.
🔹 Applications
-
General Building and Facility Maintenance (HVAC, Lighting, Piping)
-
Installation of Electrical and Mechanical Systems in Commercial Buildings
-
Routine Maintenance and Cleaning in Airports, Atriums, and Shopping Centers
-
Accessing Work Areas in Manufacturing Plants and Warehouses (Indoor Use)
-
Any task requiring articulation over fixed internal obstacles.
