Dingli JCPT1212AC Electric Scissor Lift – 39ft Narrow Aisle High Capacity AC System
Specifications
Description
Dingli JCPT1212AC Compact Electric Scissor Lift – Optimized Product Page Content
🔹 Product Overview
The Dingli JCPT1212AC is a high-performance Electric Scissor Lift classified as a “Compact Scissor,” offering a balance of reach and compact dimensions. It is ideally suited for indoor work and navigating tight spaces, providing zero emissions and low-noise operation. This model is equipped with a fully sealed AC system (drive and lift), which offers improved efficiency, water resistance, enhanced safety, and eliminates the need for brush maintenance associated with traditional DC systems. Key safety features include the automatic pothole protection system and an automatic fault code display for easy servicing. It achieves a maximum working height of 39 ft 4 in (12.00 m).
🔹 Key Specifications & Capabilities
| Detail | US Imperial | Metric |
| Max Working Height | 39 ft 4 in | 12.00 m |
| Max Platform Height | 32 ft 10 in | 10.00 m |
| Safe Working Load (S.W.L) | 705 lb | 320 kg |
| S.W.L On Extension | 249 lb | 113 kg |
| Platform Size (L×W) | 7 ft 5 in × 3 ft 8 in | 2.27 m × 1.12 m |
| Platform Extension | Unidirectional: 2 ft 11 in | Unidirectional: 0.90 m |
| Overall Width | 3 ft 9 in | 1.15 m |
| Overall Length (With Ladder) | 8 ft 2 in | 2.48 m |
| Overall Weight (Lead-acid/Lithium) | 6,746 lb | 3,060 kg |
| Drive System | Full Electric (Fully Sealed AC System) | Full Electric (Fully Sealed AC System) |
| Battery (Lead-Acid) | 24V/200Ah (Maintenance-Free) | 24V/200Ah (Maintenance-Free) |
| Driving Motor | 2×15VAC/0.87kW | 2×15VAC/0.87kW |
| Lifting Motor | 16VAC/3.5kW | 16VAC/3.5kW |
| Gradeability | 25 % | 25 % |
| Max Occupants (Indoor/Outdoor) | 2/1 | 2/1 |
| Machine Model | JCPT1212AC |
🔹 Key Features & Benefits
-
✅ Narrow Aisle Access: The narrow 3 ft 9 in (1.15 m) overall width makes it ideal for navigating standard single doorways and constricted indoor aisles.
-
✅ High Capacity for Height: Provides a substantial working height of almost 40 ft while offering a large 705 lb (320 kg) platform capacity.
-
✅ Fully Sealed AC System: The electric drive and lift systems are built with an advanced AC system, ensuring maintenance-free operation, superior waterproofing, efficiency, and safety.
-
✅ Zero Emission & Quiet: Battery-powered operation is perfect for noise-sensitive, clean environments, and finished interior spaces.
-
✅ Automatic Safety Features: Equipped with the automatic pothole protection system for stability on slightly uneven indoor floors and automatic fault code display for streamlined service diagnostics.
-
✅ Unidirectional Extension Platform: Includes an extension (2 ft 11 in / 0.90 m) for increasing the working area and accessing hard-to-reach points.
🔹 Applications
-
Interior maintenance, installation, and inspection tasks in tight spaces such as high-ceiling retail stores, hotels, data centers, and multi-story offices.
-
Projects requiring a working height near 40 feet where machine width is a critical access limitation.
-
Any indoor application that demands reliable, low-maintenance lifting with clean, quiet operation and high platform capacity.
